Airman 8
Lightweight battery-free active noise reduction aviation headset
- Sound quality
The Airman 8 features a high-quality amplified electret microphone for clear voice transmission. Improved ANR and microphone noise cancellation ensures superior in-flight communication.
- Active noise reduction
The Airman 8 headset features enhanced ANR (Active Noise Reduction) with even more noise reduction, helping to improve intelligibility and reduce fatigue. The position of the ANR switch has also moved to the forward-facing ear cup side, making it easier to reach the switch without having to remove the headset. A unique feature of the Airman 8 is that it is powered from its microphone system, eliminating the need for batteries or special connectors.
- Durability
A strong stainless steel headband with metal pivots improves durability for long headset life. The new microphone boom design provides stronger rotation stops, utilizing the full diameter of the ear cup. Furthermore, a pre-coiled overhead cord has been added to extend the useful life of the headset. The main headset cord is also more robust and features an improved design of the band relief on the ear cup entrance.
- Comfort & fit
The soft headband pad and lightweight design provides comfort, even on long flights. An added yoke provides enhanced comfort by allowing ear cup movement in all directions. Furthermore the Airman 8 comes with replaceable ear cup covers and leatherette ear cushions.
- Safety improvements
An acoustic limiter protects users against sudden increases in sound levels
- FAA TSO approval
The Airman 8 headset is fully FAA TSO C-139a compliant.
- ARINC standards
The Airman 8 is fully compliant to ARINC (Aeronautical Radio, Incorporated) requirements.
- Versions available
The Airman 8 is available in different dual-sided configurations.
The Telex Airman 8 is a lightweight noise-reducing headset designed specifically for optimizing pilot communications in commercial and business turbine aircraft. Building on the tradition of the Airman 850, the Airman 8 has improved durability, intelligibility, and comfort. The Airman 8 is one of the lightest Active Noise Reduction headsets on the market and the only FAA TSO C139a approved ANR headset to utilize Telex’s proprietary battery-free system. Soft pliable ear cushions and headband pads combine with dual direction ear cup pivots to provide long flight wearing comfort.
Specifications
| Impedance | 600 Ω (±20%) |
| Speaker Sensitivity | 93 dB SPL/ mW @ 1 kHz ±5 dB |
| Speaker Frequency Response | 350 Hz – 3.5 kHz |
Specifications |
|
| Microphone Sensitivity | -28 dB re 1 V/Pa @ 1 kHz, 12 V |
| Cord Length | ~6 ft. (1.8 m) |
| Noise Reduction | Active, up to 15 dB |
| Power Requirements | via boom microphone |
| FAA TSO Approvals | C-139a approved |
| Connector Type | PJ-068 & PJ-055 equivalent or XLR-5-12C |
| Warranty | 3 years |
| Weight | ~4.2 oz (119 g) |
