P25 CSSI Direct IP Interface

P25 cssi module for c-soft

  • Console registration
  • Group call
  • Private call
  • Call alert
  • Announcement call
  • System call
  • Short message
  • Status query/update
  • Support for up to 24 talk paths per position
  • Crosspatch between radios/talk groups
  • Radio unit monitor
  • Radio check
  • Radio detach
  • Radio inhibit
  • Emergency alarm
  • Emergency acknowledgment
  • Audio encryption and key loading

The Telex P25 Console Subsystem Interface (DFSI) option is TIA-102 compliant and allows up to 24 lines of C-Soft to connect directly to either Phase I or Phase II P25 trunked systems, thus eliminating the need for a radio gateway product such as the IP-224. Since this is a direct IP wireline connection, it can utilize the low distortion Enhanced IMBE (AMBE+2) vocoder. All C-Soft features are still available with this design, including Crosspatch, which allows legacy analog systems and/or other digital radio systems to be connected to P25 systems. Optional FIPS140-2 compliant AES-256 bit encryption is available for use with the interface.
